視頻系統

Full HD

視頻格式

1080p 50/59.94/60Hz

1080i 50/59.94/60Hz

720p 50/59.94/60Hz

視頻處理

SDI: 4:2:2

HDMI: YUV 4:2:2, RGB: 4:4:4

輸入設置（XPT）

All 12, repeatable

視頻輸入

8x SDI, 4x HDMI

相容高標清

----

電腦連接

4 via HDMI

視頻輸出

6x SDI Outputs assignable:

Multiview, PGM, PVW, PGM+DSK, Clean PGM, Clean PVW, Input 1-12, STILL 1, STILL 2, Flex source

3x HDMI assignable:

Multiview, PGM, PVW, PGM+DSK, Clean PGM, Clean PVW, Input 1-12, STILL 1, STILL 2, Flex source

下轉輸出

1x SDI

多分割畫面監看

HDMI & SDI assignable

音頻輸入

4x Balanced XLR

音頻輸出

2x Balanced XLR

支持音頻軌數

Input 2 channels, Output 4 channels

音頻延遲

Up to 16 fields or 8 frames per channel

音視頻同步切換

Yes

視頻摳像

4

字幕機

Yes, CG-200 software free download

USK

4x Keyer support Chromakey/ Linear/ Luma Key

DSK

2x DSK support Lumakey & Linear key (Key / Fill)

子母畫面

8 (4x PIP, 4x Flex Source)

LOGO顯示

2

內置靜幀圖片

999+

轉場效果

DVE, FTB, Cut, 32 Wipe with border

過場預覽

Full transitions preview

同步信號輸入/輸出

Built-in Genlock

Support external sync with loop thru

Tally輸出

1x D-sub 25pin, dual color

電腦控制

RS-232 / DVIP (Ethernet)

調音臺

----

特別功能

4 User Memory Preset

Free Virtual Set and Stinger transition included

外型

2 units, 2RU rack-mount mainframe

尺寸

433 x 312 x 76 mm (switcher)

432 x 252 x 88 mm (main unit)

重量

4 kg

電源

DC 12V, 69W

操作溫度

0~40 °C

包裝明細

1 x SE-3200 Main Unit

1 x SE-3200 Control Board

2 x AD Switch DC 12V

1 x AC Cord

1 x DB9P TO DB9P Cable

12 x Screw

2 x 2U Ear Rack
